iconApplication fields: Used in mining, building materials, transportation, energy, chemical and other industries.

iconMaximum Feed Size:700mm

iconProcessing capacity: 100-400t/h

mail Send e-mail info@hxjq.com

Product Introduction

MP module factory is a new all-around solution for aggregate crushing and screening developed by Hongxing Group according to the current domestic and overseas market environment. It is the latest international design concept. No matter your raw materials, site conditions, finished product requirements or production cycle, the design concept of MP factory combined with the high quality main machine of Hongxing Group can meet your budget and specific requirements.

Features

  1. Short construction period : All modular steel structures are produced in the factory, and the production is fast. Only a small amount of concrete foundation is needed on site, which shortens the construction period and realizes rapid production;

  2. Low investment cost : All structures are fabricated in the factory, and only on-site installation is required, saving the cost of personnel organization and leftover waste material for on-site fabrication;

  3. Convenience and flexibility : The module structure basically adopts the bolting mode, which is convenient for on-site assembly and greatly shortens the construction period. This structure is also easy to be loaded into containers for transportation and reduces freight expense

Parameter Table Of MP Series Modular Factory

MP Series Modular Factory
Production line code Maximum Feed Size
(mm)
Capacity
(t/h)
0-5mm 0-20mm 0-32mm
Hard rock MPH1 500 / 120 150
/ 130 160
100 / /
MPH2 500 / 180 220
/ 190 230
200 / /
MPH3 600 / 230 350
/ 240 360
MPH5 700 / 400 520
Medium hard
Soft rock
MPM1 500 / 120 160
MPM2 500 / 160 210
MPM3 600 / 210 300
MPM4 700 / 320 400

Note:processing Capacity May Vary With Different Materials And Feeding Sizes.
