Wheeled mobile Jaw Crusher Station

Wheeled mobile Jaw Crusher Station

Chat OnlineChat Online

iconProcessing capacity: 85-650 t/h

iconFinished size: 50-225 mm

iconApplication fields: mining, stone mining, highway (railway) construction, urban construction waste treatment, etc.

Applied materials: cement, limestone, granite, basalt, aggregate, calcite, quartz, concrete, dolomite, bluestone, iron ore, coal gangue, construction waste, ferrosilicon, etc.

mail Send e-mail info@hxjq.com

Product Introduction

The Wheeled mobile Jaw Crusher Station is a new type of crushing equipment suitable for crushing various ores or rocks with compressive strength below 250Mpa, such as construction waste, basalt, granite, coal gangue, cement clinker, iron ore, bauxite, quartz stone and so on.

In addition to Wheeled mobile Jaw Crusher Station, we also have mobile cone crushers, mobile impact crushers, mobile hammer crushers, etc. We can provide customers with a variety of configurations according to the processing of raw materials, the scale, different requirements for materials and finished products.

mobile jaw crusher applications and applicable materials

Features

  1. 1. Hydraulic lifting feeding guard plate, easy installation, and disassembly, fixed and convenient, stable and reliable.

  2. 2. The feeding guard plate adopts a grading double-layer structure, which provides a prerequisite for the personalized extension of the guard plate.

  3. 3. Adopting a ship-type steel frame, with low chassis, lightweight, and reasonably controlled volume.

  4. 4. The direct operation can help avoid the complex infrastructure installation steps and lower labor consumption.

mobile jaw crusher crushing rock stone scene

Extended Function

Mobile crusher can achieve multi-machine combination work. In a short time, the feed unit, the crushing unit, and the screening unit exchange system can be realized on the same body. The matching between the whole system can adapt to many occasions, which can greatly meet the different needs of customers. we promise 100% ex-factory price. So if you want to know something, such as prices and quotes, please ask us or send us an email: info@hxjq.com

Parameter Table Of Wheeled mobile Jaw Crusher Station

Mobile Jaw Crusher

Model HX938HD86 and HX1149HD98

Model HX938HD86 HX1149HD98
Transportation lenght(mm) 12600 13500
Transportation Width(mm) 2600 2700
Transportation Height(mm) 3870 4200
Maximum Lenght(mm) 12500 14000
Maximum Width(mm) 4100 4500
Maximum Height(mm) 4100 4900
Weight(t) 39 57
tIRE Configuration Dualaxial Dualaxial
Jaw Crusher HD86 HD98
Maximum Feeding Size(mm) 500 550
Discharge opening range 50-150 75-175
Capacity(t/h) 85-275 110-350
Vibrating Feeder ZSW380×95 ZSW420×110
Main Belt Conveyor B800×8.5m B1000×9.5m
Side-opening Belt conveyor(optional) B500×3m B650×3.5m
Gensrt(optional) 200KW 250KW
Iron separator(optional) RCYD(C)-8 RCYD(C)-10

Model HX1349HD110 and HX1349HD125

Model HX1349HD110 HX1349HD125
Transportation lenght(mm) 14500 15200
Transportation Width(mm) 2800 2900
Transportation Height(mm) 4450 4500
Maximum Lenght(mm) 16100 16700
Maximum Width(mm) 5100 5100
Maximum Height(mm) 5000 5300
Weight(t) 55 65
Tire Configuration Dualaxial Dualaxial
Jaw Crusher HD110 HD125
Maximum Feeding Size(mm) 660 800
Discharge opening range 100-200 125-225
Capacity(t/h) 215-510 280-650
Vibrating Feeder ZSW490×130 ZSW490×130
Main Belt Conveyor B1000×11m B1200×11m
Side-opening Belt conveyor(optional) B650×4m B650×4m
Gensrt(optional) 270KW 400KW
Iron separator(optional) RCYD(C)-10 RCYD(C)-12
